Product Features:
- Equipped with a high-quality speaker unit
- Exceptional reliability
- Elegant and sophisticated cabinet design
- Simple installation and user-friendly
- 2-way speaker system (4˝)
- Rotary switch for effortless tap adjustments on the transformer
Product specification
| CS-430F | ||
|---|---|---|
| Type | 4″ Two-way Ceiling Speaker | |
| Driver | LF : 8″, HF : 3″ cone | |
| Power Handling (IEC) | 30W | |
| Nominal Impedance | LOW | 8Ω |
| HI | 163 / 333 / 667 / 1.3kΩ | |
| Frequency Range (-20%) | 100Hz ~ 20kHz | |
| Sensitivity (1W/1m) | 84dB | |
| Maximum SPL | 102dB | |
| Input connection | 3P Euroblock | |
| Enclosure Material | ABS (V0) | |
| Cut-Out Diameter (Ø, mm) | Ø220 ~ 230 | |
| Weight (Set) | 1.8kg | |
| Dimensions (Net, Ø(WxH)xD, mm) | 230 x 168 | |
